Parameters |
Unit |
Specifications |
Operation Wavelength |
nm |
1270~1370 |
Angle of Incident |
° |
45 |
Pass Band Width |
nm |
1270~1306 |
Stop Band Width |
nm |
1335~1370 |
Max IL within PassBand |
dB |
<0.3 |
Transmission Isolation |
dB |
>25 |
Parameters |
Unit |
Specifications |
Operation Wavelength |
nm |
1270~1370 |
Angle of Incident |
° |
45 |
Pass Band Width |
nm |
1335~1370 |
Stop Band Width |
nm |
1270~1306 |
Max IL within PassBand |
dB |
<0.3 |
Transmission Isolation |
dB |
>25 |
Parameters |
Unit |
Specifications |
Operation Wavelength |
nm |
1260~1620 |
Angle of Incident |
° |
0 |
Pass Band Width |
nm |
1284~1288 |
Stop Band Width |
nm |
1260~1280 & 1392~1620 |
Max IL within PassBand |
dB |
<0.3 |
Transmission Isolation |
dB |
>30 |
Parameters |
Unit |
Specifications |
Operation Wavelength |
nm |
1250~1620 |
Angle of Incident |
° |
0 |
Pass Band Width |
nm |
1340~1344 |
Stop Band Width |
nm |
1260~1320 & 1366~1620 |
Max IL within PassBand |
dB |
<0.3 |
Transmission Isolation |
dB |
>30 |
