Short wave pass Filter

Parameters

Unit

Specifications

Angle of Incident

°

0

Passband

nm

350-485

Passband Average Transmission

%

>= 90%

Passband Absolute Transmission

%

>= 92%

Block Band OD > 4

nm

510~950

Parameters

Unit

Specifications

Angle of Incident

°

0

Passband

nm

350-505

Passband Average Transmission

%

>= 90%

Passband Absolute Transmission

%

>= 92%

Block Band OD > 4

nm

530~950

Parameters

Unit

Specifications

Angle of Incident

°

0

Passband

nm

350-520

Passband Average Transmission

%

>= 90%

Passband Absolute Transmission

%

>= 92%

Block Band OD > 4

nm

545~950

Parameters

Unit

Specifications

Angle of Incident

°

0

Passband

nm

350-540

Passband Average Transmission

%

>= 90%

Passband Absolute Transmission

%

>= 92%

Block Band OD > 4

nm

565~950

Parameters

Unit

Specifications

Angle of Incident

°

0

Passband

nm

350-580

Passband Average Transmission

%

>= 90%

Passband Absolute Transmission

%

>= 92%

Block Band OD > 4

nm

605~950

Parameters

Unit

Specifications

Angle of Incident

°

0

Passband

nm

350-610

Passband Average Transmission

%

>= 90%

Passband Absolute Transmission

%

>= 92%

Block Band OD > 4

nm

635~950

Parameters

Unit

Specifications

Angle of Incident

°

0

Passband

nm

350-640

Passband Average Transmission

%

>= 90%

Passband Absolute Transmission

%

>= 92%

Block Band OD > 4

nm

665~950

Parameters

Unit

Specifications

Angle of Incident

°

0

Passband

nm

350-745

Passband Average Transmission

%

>= 90%

Passband Absolute Transmission

%

>= 92%

Block Band OD > 4

nm

770~950
